Moku-Go M2

Description

1. Analog inputs/outputs- Two 12-bit, 125 MSa/s
2. Input bandwidth-30 MHZ
3. Digital I/O-16-channel @ 125 MSa/s
4. Output bandwidth-20 MHZ
5. M2 power supplies-4-channel op on

Specifications:
Analog inputs
• Two 12-bit, 125 MSa/s input channels

• 30 MHz analog bandwidth (-3 dB)

• AC or DC coupling with 1 MΩ impedance

• Input range up to ± 25 V

Analog outputs
• Two 12-bit, 125 MSa/s output channels

• 20 MHZ analog bandwidth (-3 dB, low impedance)
• ± 5 V maximum output range Digital I/O
• 16-channel DIO at 125 MSa/s
• Support 3.3 V (5 V tolerant) logic level Programming environment
• API support for Python, MATLAB, LabVIEW,& more
• Windows, macOS, iPadOS, or visionOS
• Moku Cloud Compile support for FPGA customization

Models

M0

• 2 analog inputs, 2 analog outputs & 16 DIO

• USB-C, Wi-Fi, soware, & APIs

M2
• All features from M0
• Ethernet
• 4-channel programmable power supply
CH1 +5 to -5 V @ 150 mA
CH2 0 to 16 V @ 150 mA
CH3 & CH4 Dual 0.6 to 5 V @ 1 A
